Measurement Light Curtains by ReeR Safety
Measurement Light Curtains and Automation Sensors

Manufacturer: ReeR Safety
Light curtains for industrial and civil applications where it is necessary to detect, measure, and recognize objects. Depending on the number and position of the beams engaged by an object, the measurement sensors can provide real time information to a PLC or PC in order to:
- Detect the presence or absence of objects
- Perform a count
- Detect a position
- Detect a shape or a profile
- Measure dimensions
Main characteristics of Measuring Light Curtain
OUTPUTS
- AV (0/10 VDC) analogue output,
- AC (4/20 mA) analogue output
- RS 485 serial line
- Solid state antivalent outputs 0/24V
- IO-Link serial communication protocol

This is the height controlled by the light curtain

This is the maximum working distance that may exist between the emitter and the receiver

Synchronisation between emitter and receiver Optical or via cable, selectable

Distance between the optics of the measurement light curtains. 5, 10, 25, 30, 50, 75 mm
Literature
