Ruggedized Control Units by Inxpect
UNMATCHED RELIABILITYAND DURABILITY
Discover the state-of-the-art ruggedized Inxpect control unit, designed to deliver exceptional performance even in the harshest conditions, making it the ideal choice for challenging environments and industrial applications.
Key Features:
IP67 Certification: Maximum protection against dust and water.
Resistance to vibrations in accordance with:
- IEC 60068-2-64 Fh (equipment in wheeled vehicles, Spectrum A.3)
- IEC/EN 61496-1:2020 (ground vehicle installations, 5M3)
- ISO 15003:2019 (agricultural machinery, L3)
Ideal Applications:
Heavy Industry: Perfect for environments with high levels of dust and humidity.
Agricultural Sector: Withstands weather conditions and soil environments.
Construction: Reliable on construction sites, resistant to dust and vibrations.
The system is equipped with a Type B Control Unit, and an SD card is pre-installed by default in all versions.
Made for harsh environments
Broadband random vibration
In accordance with IEC 60068-2-64: Fn, Spectrum A.3, equipment in wheeled vehicles, Category 1 (8h/axis).
Sinusoidal and broadband vibration for ground vehicle installations
In accordance with IEC/EN 61496-1:2020 sec. 5.4.4.1 class 5M3 (IEC60068-2-6 and IEC 60068-2-64).
Shock test for ground vehicle installations
In accordance with IEC/FN614961:2020 sec. 5.4.4.2 class 5M3 (IEC 60068-2-27).
