Manufacturer: IAI Intelligent Actuator

IAI EC ELECYILNDER – A New Era of Switching Air to Electric Actuators

Designed for simplicity from start-up to maintenance

Ushering in a new era of easy electric cylinder control, the easy Elecylinder is designed for simplicity from start-up to maintenance. Speed / Acceleration settings can be set in just 5 minutes. No time-consuming programming is necessary.  You can also operate it with ON / OFF signals, like a solenoid valve. No time-consuming programming is necessary.
Air cylinders cannot operate at high velocity due to the impact at stroke end which occurs when excess velocity is applied.  The ELECYLINDER can start and stop smoothly at high velocity, reducing cycle time.

  • Maintains excellent velocity stability even in the low velocity range
  • Acceleration, velocity and deceleration (AVD) can be set individually
  • Teach pendant troubleshooting for easy diagnostics and repair
  • Start and end points can be set at any value
  • Battery-less absolute encoder means no maintenance required
  • Built-in controller requires no control panel space
  • Reduces electric bills, the higher the operational frequency, the greater the savings

Simple Operation without Programming

You can quickly setup movement just by entering data. You can also operate it with ON / OFF signals, like a solenoid valve.
No time-consuming programming is necessary.

Easily Adjust AVD Settings Individually

Enter the movement conditions.

Easily Repairable in the Event of a Breakdown

Troubleshooting can be performed using the teaching pendant.
Device stoppage causes and countermeasures are displayed.
In nearly all cases, just replace the motor or controller circuit board yourself and the unit will recover.

Easily Reduce Cycle Time

Air cylinders cannot operate at high velocity due to the impact at stroke ends which occurs when excess velocity is applied.
The ELECYLINDER can start and stop smoothly at high velocity, reducing cycle time.

Long Service Life

Instead of an impact mechanism, the ELECYLINDER incorporates a ball screw and ball circulating type built-in linear guide to achieve a long service life.

Based on calculation using the conditions below, the lifespan of the ELECYLINDER is five times longer than that of air cylinders
